Basket Strainers

Hellan Strainer

Hellan Strainer manufactures a wide range of manual and automatic strainers for industrial applications. Hellan industrial strainers combine reliable filtration with durable construction and innovative designs that allow for fast and easy cleaning and maintenance. With a variety of sizes and configurations available, it’s easy to find the right Hellan industrial strainer for your specific needs.

Cooling Water

When mission critical industrial systems requiring cooling water Hellan Strainers is your solution. Highly reliable filtration with durable construction the Hellan Strainers protect cooling towers, heat exchangers, compressor stations, etc.

Off-Shore Installations

For reliability and dependability in harsh seawater environments, offshore oil rigs and FPSO (floating production, storage, and offloading) vessels count on Hellan’s industrial strainers. They’re used in fire water deluge systems, in fuel filtration, in cooling systems that protect process equipment, and much more.

Oil & Gas

Hellan’s industrial strainers can be used to protect equipment like heat exchangers and pumps, to remove contaminants from process water, to strain water for cooling towers, and in fire protection systems. Hellan Strainers are designed to deliver robust, reliable performance even in the often-harsh working conditions of the petrochemical industry.

Fire Protection

Hellan’s fire protection system strainers feature a patented self-cleaning design that eliminates clogged nozzles and unreliable water flow, leaving no doubt that your fire protection system will perform as needed. Hellan Strainers are tested and UL-approved for use in all types of fire protection systems.

Marine

Hellan Strainers are used in numerous capacities in marine shipping and cargo applications. They’re used on FPSO (floating production, storage, and offloading) vessels to protect plate and frame heat exchangers; they’re used on cargo ships to cool sonar/radar navigation systems; they’re used on cruise ships to protect stern tube shaft seals. Hellan Strainers deliver superior performance and reliability in any application.

Irrigation

With water that is usually pumped in from lakes and rivers, irrigation water supplies must contend with a wide array of contaminants: pipe rust, sediment, debris, even fish! These contaminants can clog pipelines and damage nozzles. The innovative designs of Hellan Strainer products will minimize the maintenance and repair costs of any irrigation system.

Power Generation

Hellan Strainers are proven effective in all power generation applications: hydroelectric, gas/fossil fuel, nuclear, etc. Hellan’s industrial strainers feature innovative and durable designs that will remove fish, mussels, and other potentially-problematic aquatic creatures, as well as sand and grit, from lake and river water to protect plant equipment.

Steel Mills & Foundries

Hellan Strainer products can be found in blast furnaces, open hearths, continuous casting mills, and other iron and steel plants throughout the world. Used for recirculating water, descaling water, and cooling water, Hellan industrial strainers deliver superior performance in harsh working environments and help reduce maintenance and operational costs.



Applications:

MARINE:

• Military: Strain seawater used for cooling in the following
• systems:
• Lube Oil Cooler
• Cooling Pumps
• Gas Turbine Generators
• Shaft Seals
• High and Low Pressure Air Conditioning
• Distilling Plants
• Sonar
• Phalanx
• Radar Cooling
• Fire Protection
• Remove debris from incoming seawater aboard all types of ships in commercial and naval markets.
• Protect electronics (sonar, radar) equipment (HV AC, lube oil coolers, fuel oil), and weapons (phalanx guns) aboard naval ships.
• Filter out suspended solids in bilge, galley and graywater to meet international water quality standards for discharged water from all types of ships.



OIL REFINERIES:

•  Cooling water for diesel engine on towboat.
•  Service water for general plant use.
•  Semi-solid oil.
•  Water for cooling non-metallic bearings.
•  Sea water for cooling and process use.
•  Removing suspended petroleum fines from water.



CHEMICAL PLANTS:

• Water from cooling tower water for various heat exchanges in chemical plant.
•  Lake water for compressor heat exchangers.
•  River water for air conditioning condensers.
•  Well water for general plant services in chemical plant.
•  River water for general plant use.
•  Cooling water for air compressor.
•  River water for alcohol still house.
•  River water for processing ammonia plant.
•  Cooling water in ammonia plant.
•  River water for condensers.
•  River water for spray nozzles.
•  River water at pump pit distillation house.
•  River water for cooling purposes.
•  Sea water for processing at chemical plant.
•  General plant service water.
•  Anhydrous ammonia liquor.
•  Process water.
•  Plant hydraulic system.
•  Water filtration and treatment plant.
•  Removing sand and moss from lake water.
•  Removing polyethylene fines.
•  Cooler spray water.
•  Fire protection systems



PULP AND PAPER PLANTS:

• Remove fibers from white water filtrate for nozzle protection.
• Remove silt and solids from river water to protect sand filters.



AUTOMOTIVE PLANTS:

•  River water ahead of needle valves.
•  Service water.
•  River water for general plant use.
•  Cleaning sodium metasilcate washing solution.
•  Cooling water.
•  Ahead of sprays on automatic car wash system.
•  Water for welding units.
•  Removing scale from quenching water in heat-treating process.
•  Cleaning up closed system-cooling water on battery of flash welders.
•  Cooling tower water.
•  Recirculated water for engine test stand.
•  Light oil for central cylinder test system.
•  Light oil used for metal machining center.
•  Recirculated water for cooling transformers and welding robot tongs.
•  Washwater for gear parts.
•  Cleaning solution for various operations.
•  Fire protection systems



GENERAL INDUSTRY:

•  River water for oil-water heat exchanger on lube system.
•  River water for cooling large electric motors.
•  Water from cooling tower for cooling large motors.
•  Side-loop for filtering water Recirculated through cooling tower.
•  River water for grid heating system.
•  Water-oil emulsion for testing tubes.
•  Emulsion for pipe testing press.
•  River water for fire protection system.



IRON AND STEEL PLANTS:

•  Water from slag granulating pit.
•  River water for general plant use.
•  River water for high pressure descaling nozzles.
•  Lake water for precipitator.
•  Lake water for waste heat boilers.
•  River water for coke ovens.
•  Mill service water.
•  Water for non-metallic bearings in rod mill.
•  Canal water for general plant use.
•  Canal water for DX machine.
•  Water for open hearth cooling.
•  Water for blast furnace gas cleaning plant.
•  Canal water to cool mill bearings.
•  River water ahead of primary gas washer.
•  Removing sand from well water.
•  Reclaimed mill-cooling water.
•  Water for pickling sprays
•  Removing animal hair from descaling water.
•  Quenching water for forging department.
•  River water for tubular type air cooler.
•  River water for spraying at blast furnace department.
•  Recirculating water for mill sprays.
•  Removing tar in tar pumping system at coke ovens.
•  Ammonia flushing liquor in recirculating system at coke ovens.
•  Removing scale and grit in roll cooling water.
•  Pipe mill supply water.
•  For gas washer disintegration nozzles.
•  Blast furnace-cooling water.
•  Water entering blast furnace gas washers.
•  Inlet water to hydraulic waste heat boilers.
•  Cooling water in sintering plant.
•  Removing foreign particles ahead of 3" cyclone.
•  Cleaning water for scarf er at 44" blooming mill.
•  Removing scale and grit from water circulating system in ot strip mill.
•  Removing sludge and scale from quenching oil.
•  Mill scale from bearing cooling water.
•  Water for cooling and general service in tar distillation plant.
•  River water for slab mill.
•  River water for welded tube department.
•  Water for roll cooling.
•  Water for electrolytic tinning line.
•  Water for blast furnace gas washer.
•  Water for four-sided scarfer at slab mill.
•  River water to spray nozzles in rod mill cooling lines.
•  Removing coal particles from boiler feed water.
•  Water ahead of pressure pu1nps on blast furnace gas washer.
•  Process water for tin mill.
•  Recalculated water for cold rolling mill spraying operation.
•  Cooling tower water for in old cooling and spraying in continuous casting process.
•  River water for cooling blast furnace gas enclosure. ,
•  Recalculated water for cleaning granular at blast furnace.
•  Cooling tower water for cooling panels in furnace.
•  River water for quenching steel.
•  Cooling water for stretcher-leveler.
•  Lubricating oil to roll bearings.
•  Cooling tower water for foundry heat exchangers on power units and air compressors.
•  River water for cooling foundry furnaces.
•  River water for cooling forging presses.
•  Recycled water used in tub vibrator in diecasting operation.
•  Ammonia flushing liquor in recirculating system at coke ovens.
•  Removing scale and grit in roll cooling water.
•  Pipe mill supply water.
•  For gas washer and disintegrate nozzles.
•  Blast furnace-cooling water.
•  Water entering blast furnace gas washers.
•  Inlet water to hydraulic booster pumps.
•  Water for open-hearth waste heat boiler.
•  Cooling water in sintering plant.
•  Re1noving foreign particles ahead of 3" cyclone.
•  Cleaning water for scarfer at 44" blooming mill.
•  Removing scale and grit frmn water circulating system in hot strip mill.
•  Removing sludge and scale from quenching oil.
•  Mill scale fro1n bearing cooling water.
•  Water for cooling and general service in tar distillation plant.
•  River water for slab mill.
•  River water for welded tube department.
•  Water for roll cooling.
•  Water for electrolytic tinning line.
•  Water for blast furnace gas washer.
•  Water for four-sided scarfer at slab mill.
•  River water to spray nozzles in rod mill cooling lines.
•  Removing coal particles from boiler feed water.
•  Water ahead of pressure pumps on blast furnace gas washer.
•  Process water for tin mill.
•  Gas washer water.
•  Water for coke plant wash house.
•  Water for oil coolers.
•  Booster water for hot strip mill stands.
•  Service water for DX machines.
•  Water for blast furnace air conditioners.
•  Removing slag and hot scarfing operations.
•  Removing sand and other debris from cooling water.
•  For blooming mill rolls and bearings.
•  Ammonia flushing liquor in the discharge line after flushing liquor pumps.
•  Removing sand to prevent clogging of water sprays on cold reduction mills.
•  Water for roll sprays and hydraulic pumps.
•  Water for centrifugal pumps.
•  Cooling water for roll necks.
•  Water for blast furnaces gas cleaning equipment.
•  Cooling water for gas generator.
•  Cooling water for annealing furnaces.



PLASTIC:

• Recirculated water for cooling tooling on injection molding machines.
• Recirculated water for cooling resin pellets.
• Well water for spray jets and cooling conveyors in resin production.



POWER PLANTS:

•  Removing sand, grit, foreign matter from river water.
•  Water for cooling bearings.
•  Turbine auxiliary cooling water.
•  House service water.
•  Water to rubber bearing and rubber seated pumps.
•  Cooling water for auxiliary equipment such as small oil coolers, bearing coolers, generator bus cooling,  heater drainpipes, pulverizing mills, main boiler feed pumps, condensate pumps and vacuum pumps.
•  Circulating water for the condensate cooler.
•  Temperature-controlled cooling water to main turbine oil coolers.
•  Cooling water for steam heating plant.
•  Removing animal hair from river cooling water.
•  Water for turbine sealing.
•  Pre-filtration of river water for various plant services.



PULP AND PAPER PLANTS:

•  Pre-filtration of river water for multiple plant services.
•  Creek water to heat exchangers for various cooling functions.
•  River water for spray system nozzles.
•  Straining concentrated sulfite liquor.
•  River water for processing ammonia plant.
•  River water for papermaking and to relieve load on sand filters.
•  Handling fresh filtered water supply to paper machines and refining beaters.
•  Cleaning water in conjunction with settling basin.
•  River water for general plant service.
•  Canal water for processing and cooling purposes.
•  Water for sulfite plant.
•  Ammonia liquid.
•  Removing foreign matter from water to spray nozzles on bark removing machine.
•  Accumulator water.
•  Well water.
•  Post alum flocculation ahead of hot water ,showers on recovery boiler.

TIRE AND RUBBER PLANTS:

•  Removing particles of rubber from cooling water.
•  Cooling water for Banbury rubber mixers.
•  Cooling water for tire and tread mills.

MISCELLANEOUS:

• Lake water used for cooling in various foods processing operations.
•  Water for jet spray systems in mines.
•  Water for jet spray used in ore treatment.
•  Brackish water for desalination plant.
•  Water used in wool dyeing process.
•  Filtration of sucrose-water solution in sugar process to remove cooking and corrosion residues.



Hellan Strainer D-Series





Hellan Strainer QA-Series

(20" Bronze Strainer)





Fabricated Simplex Basket Strainer for Seawater Service

(16" Super Duplex Stainless Steel)
